Linear Systems [Hardcover]

Linear systems have all the necessary elements (modeling, identification, analysis and control), from an educational point of view, to help us understand the discipline of automation and apply it efficiently. This book is progressive and organized in such a way that different levels of readership are possible. It is addressed both to beginners and those with a good understanding of automation wishing to enhance their knowledge on the subject. The theory is rigorously developed and illustrated by numerous examples which can be reproduced with the help of appropriate computation software. 60 exercises and their solutions are included to enable the readers to test and enhance their knowledge.

Preface xi

Introduction xvii

Chapter 1. Reminders and General Points 1

1.1. Lines 1

1.2. Adaptation and stationary waves 4

1.3. Smith chart 6

1.4. Power in a line 6

1.5. Line sections 7

1.6. Lines with losses 9

Chapter 2. Measurements in HF 11

2.1. Material 11

2.2. The power bench11

2.3. Measurements on the network analyzer 14

Chapter 3. Resonant Cavities 25

3.1. Resonance 25

3.2. Coaxial cavities 28

3.3. Quarter-wave cavities 29

Chapter 4. Fabrication and Tuning of Cavities 47

4.1. Standard structures 47

4.2. Materials 53

4.3. Assembly 56

4.4. Temperature stability 58

4.5. Cavity tuning 70

Chapter 5. The Band-pass Filter 83

5.1. The band-pass function 83

5.2. Calculation of a
