Modeling of Complex Systems: Application to Aeronautical Dynamics [Hardcover]

In the field of aeronautical dynamics, this book offers readers a design tool which enables them to solve the different problems that can occur during the planning stage of a private project. The authors present a system for the modeling, design and calculation of the flying qualities of airplanes and drones, with a complete mathematical model by Matlab/Simulink. As such, this book may be useful for design engineers as well as for keen airplane amateurs.

The authors expound the various phases involved in the design process of an airplane, starting with the formulation of a design tool, under the form of a 0D mathematical model (dimensionless, time dependent), before moving on to explore the behavior of the airplane under certain circumstances and offering insights into the optimization of airplane flying qualities. As validation of this model, they present a numerical result, drawn from data collected on an existing plane  the Concorde.

The dimensional process is then explored and applied to a realistic drone project. Recommendations on the development of the principal characteristics of the plane (i.e. mass distribution, air load, wing span) are given.

Introduction vii

Chapter 1. 0D Analytical Modeling of the Airplane Motions 1

1.1. References: axis systems on use 2

1.1.1. Galilean reference: R0 2

1.1.2. Airplane reference: RB (body) also called linked reference 2

1.1.3. Resultant angular velocity 6

1.2. Equations of motion of the airplane 9

1.2.1. Expression of Newtons principle 10

1.2.2. Expression of the dynamic momentum 11

1.3. Description of external forces and torques 14

1.3.1. Aerodynamic forces and torques 14

1.3.2. Sign rules 17

1.4. Description
